120MW Ansaldo Gas Turbine Generator Set for Sale
50Hz. 15kV Fuel: Blast Furnace Gas, Coke Oven Gas & Natural Gas.
Model V94.2 "K" Commissioned 1999. Major overhaul (hot gas path) 2012. 8,700 hours since overhaul. Total hours 108,242.
Machine preserved at shutdown Preservation maintained. Steam injection.

 Milt Fyre   503-351-9898 or milt@rmaglobal.com

              Commissioned:

Decommissioned:

Lifetime Service Hours:

Lifetime Hot Starts:

Lifetime Cold Starts:

Last Major Overhaul:

Overhauled By:

Type of Overhaul:

Service Hours - AfterOverhaul:

Hot Starts – After Overhaul:

Cold Starts – After Overhaul:

Preservation Procedure:



1999

31st December 2013

108,242

716 (incl. failed starts)

510 (121 @ high rate ramp)

October 2012

Ansaldo Energia

Hot Gas Path Inspection

8,684

63 (incl. failed starts)

60 (26 @ high rate ramp)

Machine preserved at shutdown Preservation maintained



GAS TURBINE MAKE

Model:

Licensor:

Type:

Fuel:



Base Load Rating;



Dry Operation;

Power:

Heat Input:

Fuel;

AFO:

COKE Oven Gas:

Natural Gas:

Fuel LHV:



With steam inj.;

Power:

Heat Input: Fuel;

AFO:

COKE Oven Gas:

Natural Gas:



Fuel LHV:

Fuel Gas Comp.:

Ansaldo Energia S.p.A. (Genoa, Italy)

V94.2 “K”

Siemens AG, Germany

Heavy duty gas turbine

Blast Furnace Gas, Coke

Oven Gas & Natural Gas mixture



-

112,000 kWe

380 MWt

112,000 Nm³/h

19,000 Nm³/h

18,740 Nm³/h

2,180 kcal/Nm³



-

120,000 kWe

480 MWt

56,000 – 120,000 Nm³/h

15,000 – 22,000 Nm³/h

As necessary to achieve

required Heat Input.

2,200 – 3,300 kcal/Nm³

~ 23 MW (driven off turbine shaft)





Generator:

Manufacturer:

Mode:

Apparent Power:

Active Power:

Power Factor:

Rated Speed:

Voltage:

Current:

Phases:

Connection:

Frequency:

Standard:

Service:

Protection:

Insulation Class



Ansaldo Energia s.p.a., Genoa, Italy

WY21Z-073LLT

141,000 kVA

112,800 kW

0.8

3,000 rpm

15,000 V

5,427 A

3

Y

50 Hz

IEC 34.1 (1987) / CEI 2-3 (1988)

S1

IP 54

F / F
