Power Plant Parts and Components and Turbine Blades
Return to Power Plant Index
Listed 2/9/08
192MVA Westinghouse Generator for sale. (This is a generator only.) Nominal Power : 192MVA, Generation Voltage : 13.8kV, Power Factor : 0.85, Nominal Current 8,032A, Rated Speed : 3600 rpm, Frequency : 60Hz., 3 Phase, Hydrogen Cooled 45psig. Less than 2,000 total hours. Like new condition. (Click here for image.) Contact for price. Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 1/28/08
Turbine Blades for sale: GE Frame 7FA 2nd stage buckets 172 each, part no. # 116E2013/K2BM 0129081/VNK/GMIB/9 hole blades/, taken from a 7242 natural gas turbine with 24,000 hrs. No documentation, as is. (Click here for image.) asking $ 65,000.00 Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 11/2/07
100kVA Overhead Distribution Transformer (ABB) (7 units for sale): SP- Surge Protecting No Load: 154 Watts at 85 degrees C; Load: 803 Watts at 85 degrees C; Total Loss: 957 Watts 7200/12470Y x 14400/24940Y HV; 125* 125 BIL; Copper HV Winding Material, 120/240 LV; 30* 30 BIL; Non-LV Interlaced; Aluminum LV Winding Material, 60Hz. 1 Phase Transformer Weight; 1211.24 lbs.; Height 53 in.; Width 32in.; Depth33.00 in. 65 Temp Rise; 1 DV Switch, ABB, External (lever) Handle, 1 Deck, PLT 7.2 x 14 2 HV expulsion fuse: 15kV; 18E wire; curve #7 1 HV Line Bushing, 125kV BIL, 17.75" Creep, 8-2 size eyebolt, scre 1 HV Neut Bushing, 125kV BIL, 17.75" Creep, 8-2 size eyebolt, scre 3 LV Bushings, Double Eye Bolt for 2/0-1000MCM, Porcelain 46 Gal(s) of Transformer Oil 1 Oil Drain, Pipe plug .50, bronze hex head 1 Arrestor; 19kv Lrg Blk Mov Polymer (5151B44G01) Asking $4,000 each. Pete Hoffman 503-595-5418 pete@rmaglobal.com
Listed 10/2/07
Transformers for sale: Pad Mounted Distribution Transformers (oil filled), single phase, never used, 60Hz., for sale as a lot (173 units). Pad Mounted (Oil Filled) Single 10kVA 15kVA 25kVA 37.5kVA 50kVA 75kVA 100kVA 167kVA All 7200/12470Y primary and 120/240 secondary. (Click here for list) contact Pete Hoffman 503-595-5418 pete@rmaglobal.com
Listed 9/19/07
Sootblowers: Suitable for Wood/coal/biomass boilers (10MW to 25MW). The blowing medium is steam.
5 each - Clyde Bergemann Sootblowers - Model: RKT 7' 8 ½" (7' 8 ½" is the length of the blowing lance) W-275-SB-1022
Fully retractable unit. 3 each - Clyde Bergemann Sootblowers - Model: RKS 17' 7 ½" (17' 7 ½" is the length of the blowing lance). New never been used - just a little weathered from being outside. (Click here for images.) New Price at Factory: $20,000 each. Asking $6,000 each. Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 11/15/06
GE Frame 7 Gas Turbine Generator Combustion Parts. (click here for details) Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 9/15/06
Surface Condenser - Graham Model 58 70 / 17.67 TBTD, 108,500 lb/hr., heat rejected 100,000,000 btu/hr., circulating water 9,718 gpm. Surface area 7,626/7545. Built in 1989 and shut down in 1996. Very low hours and in immaculate condition. (click here for details) (Click here for images 1 2 3 ) $120,000. Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 12/1/05
115kV Pascor disconnect switches for sale (4 each). CBPC 115/1200/550/61. 3-pole single throw. Center side break with copper live parts. Rated 115KV (121KV max) 1200 amp continuous, 550KV BIL, 61kA momentary, 60Hz. 12'-0" phase spacing. Centerline-centerline. Weight 400 lbs. Include worm gear operator, arcing horns, operating mechanism for phase over phase, Underhung mounting on a transmission tower NGK-Locke TR-286 insulators with "semi-con (resistance) glaze, shipped assembled with switch. ANSI gray color. $10,000 each. Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 8/15/05
GE Frame 5 & 6 Gas Turbine Parts for Sale, Frame 6B 1st & 2nd Stage Buckets & Shrouds. Frame 5 2nd Stage Buckets.
(Click here for more information) Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 2/25/05
Frame 5 and LM2500 Parts for sale:
First stage buckets, 733E0831P105, $ 21,780 per set. Two sets are available.
First stage shrouds, 722C0163P003/004, $ 3,300.00 per set. Two sets are available.
First stage shrouds, 339A9970G004, $ 7,700.00 per set. One set is available.
One LM 2500 P# 9101M29G77 Combustor in overhauled condition. $104,500.00. Overhauled by Chromalloy. Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 2/24/05
Power Poles 75' to 95' (metal) for sale. We have 26 Valmont Power poles (new) for sale for a fraction of their original cost and we will consider all reasonable offers. VALMONT POWER POLES:
90' AGH, Class 32, SVD-3STR2, A9771 power poles
80' AGH, Class 32, SVD-3STR3, A9771 power poles
75' AGH, Class 12, VIP STR5, A9771 power poles
80' AGH, Class 12, VIP STR7, A9771 power poles
80' AGH, Class 20, SVS-3 STR9, A9771 power poles
95' AGH, Class 32, SVD-3 STR10, A9771 power poles
95' AGH, Class 24, VISL STR11, A9771 power poles
We have more in stock. We can provide Power Pole Specifications (PDF file) on request Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 12/08/04
GE Speedtronic MK11 parts for sale. New and used. (Click here for more information.) Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 6/25/2004
Remote Fuel Coolers, Model AO-40 manufactured by Thermal Transfer Products. Originally used with CAT 3516B, 2000 kW diesel generators. Engines had less than 20 hours of run time. Includes ½ HP single phase fan motor. Priced at $495. 10 available.
Fiberglass Battery Boxes for (2) Size 4D diesel engine starting batteries. Color is gray. Exterior dimensions: 49.5”L x 12.75”W x 16”H. Priced at $175 each. 35 available.
Spring Isolators - Seismic Rated Caldyn Model RJSD-3920K with earthquake restraints. Originally used with CAT 3516B, 2000 kW diesel generators. Engines had less than 20 hours of run time. Base is 10”L x 9”W with 5½” operating height. Isolators are primer painted only, stored indoors. $85 each. Contact Pete Hoffman 503-595-5418 or pete@rmaglobal.com
Listed 6/24/2004
Engine Silencer - Hospital Grade Diesel Engine Silencer (18” Side Inlet, 18” End Outlet). Silencer is EM Products Model JHS-18X-205414, manufactured in 10/00. Originally used with Cummins DQKC, 2000 kW generator set with 17 hours of run time. Includes 90º exhaust elbow and rain cap. This silencer is currently stored inside. Dimensions: 48” diameter x 20’ overall length including exhaust elbow. Priced at $1,800 each. Only one available. Contact Pete Hoffman at 503-595-5418 or pete@rmaglobal.com
Listed 6/24/2004
Exhaust Silencers - Super critical, low profile dual inlet (pancake style) exhaust silencers. Silencers are Harco Manufacturing Co. Model 9628SFH 12x12x20 with (2) 12” flanged inlets and a 20” flanged outlet. Originally used with CAT 3516B, 2000 kW diesel generators. Engines had less than 20 hours of run time. Silencers have been in inside storage. Dimensions: 96” diameter x 28” body height. 12 available. Price is $2600 each. Click here for manufacturers documentation in pdf. Contact Pete 503-595-5418 or pete@rmaglobal.com
Listed 10/09/2003
Two-Deltak 2 Drum HRSGs for LM6000s $1.9mm each. 650-950 Psig sliding, + 40 psig; includes supp fire. Contact Lane Kadel 503-595-5418 or lane@rmaglobal.com
Listed 10/09/2003
One-Deltak 2 Drum HRSG for GE 7EA 650-950 Psig sliding, + 40 psig; includes supp fire Price $3.7mm Contact Lane Kadel 503-595-5418 or lane@rmaglobal.com
Listed 03/27/03
GE MKII Control system for LM2500. Available in early May, 2003. Call for pricing. Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com.
Listed 02/21/03
Frame 5LA parts. Various GE 5001LA gas turbine parts. Click here for complete list. Call for pricing. Contact Lane Kadel 503-595-5418 or lane@rmaglobal.com.
Listed 01/02/03
3 EMC Symmetrix (Sym 5's) units for sale:
System 8730 (3 bay): $125,000, System 8430 (1 bay): $50,000, and System 3830 (1 bay): $25,000. The 8730 and the 8430 are new and were never installed. Software in sealed boxes. Units are certified. For more details on each, click here. Contact Lane Kadel at 503-595-5418 or lane@rmaglobal.com.
Listed 12/31/02
*Sale* Equipment from Cutler-Hammer, Marconi, Astec, Industrial Electronics, and many more! For a complete list, click here. Contact Randy Klohmann at Hackney Power 317-844-1730 or randykloh@hotmail.com.
Listed 12/04/02
Power Rectifier - Dynatrol Power Unit Model # SR92-01010503-GKLX-69XX (serial no. 950176) was made in 1995 by the Vermont based company, Dyna Power, and the grey Switch Gear/Breaker units were manufactured by Hyden Switchgear Products Corp. out of Buffalo, NY and sold by IEM out of Fremont, CA. The Dynatrol unit was used for a short period approximately six months and was then shut down in 1996 never to be used again. The following is from the front sheet of the Dynatrol Power unit's operating manual:
AC input 12,470 Volts 3 PH 60 HZ 281 AMPS 6067 KVA
DC output 100 Volts 50,000 AMPS 5000 KW 3.4% RIPPLE
(Click here for pictures) (Click here for diagrams) $255,000 Contact Lane Kadel at 503-595-5418 or lane@rmaglobal.com
Listed 11/10/02
High/medium voltage transformers. All have been tested and are certified PCB free. About 20 available. For a sample list, click here. Make offer. Contact Lane Kadel 503-595-5418 or lane@rmaglobal.com.
Listed 11/14/02
LM6000 Simple Cycle Balance of plant equipment (new) for 4 LM6000s. 2 cooling towers, 1 5000-kVA Padmount Transformer, 6 gas compressors, 4 chillers, 2 SCRs, 1 emissions monitoring system, 2 air compressors, 8 Demin. Tanks, 245kV circuit breakers, 230kV switch gear and insulators, 12,000 ft. 230kV underground cable, 5kV & 15kV switch gear (The LM6000s available separately from other sources.) (Click here for more details) Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed
8/20/02
New 2001 - Special sale of substation and power plant
equipment including Alcad battery backup system 97 & Siemens
115kv circuit breaker (Click
here for details) Contact Jim Michael @ Northwest Regional Power (509)
773-5650 or jmichael@rossmgt.com or Lane Kadel @
RMA (503) 595-5418 or lane@rmaglobal.com
Listed 3/18/02
Deltak Dino - 5460 Heat Recovery Steam Generator. The HRSG is designed to be connected to a G.E. Frame 7FA gas turbine. High pressure steam outlet 1325 PSIG at 920 deg. F Low Pressure Steam outlet 50 Pressure Steam outlet 50 PSIG @ 350 deg. F. The unit is equipped with 300 MMBTU duct burners to increase steam output from 580,000 lb/hr to 900,000 lb/hr. 225 Feet of stack is included with the unit. The unit is new, (never installed), and available for immediate sale. Contact Lane Kadel 503-595-5418 or lane@rmaglobal.com. Call for price.
Listed 02/25/02
Boiler - Model 2100C Raypack water tube boiler; Serial # 9704139272; Built 1997; Capacity 2,100,000 BTUs; Output 1,700,000 BTUs with forced air flue and circulating pump. Used in Texas during the winter of 1998, 1999 and 2000. Taken out of service in October of 2001. Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 02/25/02
Cooling Tower - Marley Aquatower; Serial # 76174-1/B22154A/4852; Capacity 50 tons; installed March 1995, SH229-436; B22154A-4850; TWR-EFF-3/31/95; Belt size 2 2/A120 Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 01/28/02
1 (one) Trench Dry Type Air Core Shunt Reactor. 66Kv/50hZ. Click Here For Details Price $150,000
Contact Lane Kadel 503-595-5418 or lane@rmaglobal.com
Listed 08/23/01
Two newly rebuilt Dresser Rand reciprocating gas compressors; process 7800lb/hr. each of CPUC natural gas; compress from 150 psig to 300 psig. Complete, skid mounted with motor (200 HP, 1800 RPM, 460/3Ph/60Hz), motor starter (Class 1, Div 2), pulse dampeners, after cooler, all instrumentation. Full warranty, ready for immediate shipment. $420,000 for the pair but will split up for sale. Contact Milt Fyre 503-595-5418 or milt@rmaglobal.com
Listed 07/25/01
Two (2) 13.8kV Delta - 4160Y V Substation Transformers. 15660/20880/26100 KVA, Westinghouse, 3 phase, 60 Hz, Class OA/FOA/FOA, Type SL, 5.67% Impedance, Top mounted bushings, with bus duct flange mounting, MFG. 1986, 65 degrees C rise, low voltage brought out in two parts High voltage: 13.8 KV Delta, BIL: 110 KV, Low Voltage: 4160Y/2400, BIL: 75 KV. With 2 plus and minus 2-1/2% taps. Total weight: 122065 lbs., Core & coils: 65500 lbs., Tank & fit: 26265 lbs., Oil: 30300 lbs 4040 Gallons (shipping weight with oil in tank: 85,165 lbs) Dimensions: 158"H x 92.5"D x 154"L Recently refurbished; 12 month warranty. Price each $175,000 FOB Factory; Looking for immediate sale.
Contact Milt Fyre at 503-595-5418 or milt@rmaglobal.com
Listed 06/18/01 Sold - Sold - Sold by RMA
Bio-Mass Pellitizer!! One Lundell Model 1200 Densifying System. This machine primarily intended for corrugated paper and other types of paper products. It has been successfully operated in other Bio-Mass Plants. Includes Shredder-Mixer, Densifier, and Carry-Away Cooling Conveyor. Owner Must Sell. Worth about $500,000, List Price is $50,000, and owner will take all offers. Must sell. Contact Lane Kadel at lane@rmaglobal.com or 503-595-5418
